Android Application with Vue.js, Ionic Framework and Laravel API: Part 1

updated on

Overview

In this first part of the series, we will guide you through setting up a Laravel API server hosted on an AWS EC2 instance (Free Tier) with a MySQL database on Amazon RDS. We will cover the EC2 server setup, Laravel installation, Sanctum configuration for token-based authentication, Apache vhosts configuration, using Route 53 for domain management, and securing your server with SSL via Let’s Encrypt.

Prerequisites

  • AWS (Free Tier account).
  • EC2 instance running Ubuntu 22.04.
  • RDS MySQL database.
  • Basic knowledge of Laravel, Ubuntu, and command-line tools.

1. Setting up the Server

Launching an AWS EC2 Instance

  1. Start by creating an Ubuntu 22.04 EC2 instance eligible for the AWS Free Tier.
  2. Assign a security group with HTTPS (port 443) and SSH (port 22) access to the instance.

Installing the LAMP Stack

Once your instance is running, SSH into it and install the LAMP stack:


sudo apt update
sudo apt install apache2 mysql-server php php-mysql libapache2-mod-php php-cli php-xml php-mbstring unzip curl

Configuring Apache for Laravel

Create a directory for your Laravel application and adjust permissions:

sudo mkdir -p /var/www/api.example.com
sudo chown -R www-data:www-data /var/www/api.example.com
sudo chmod -R 755 /var/www/api.example.com

Cloning Your Laravel Repository

Clone your Laravel project repository into the created directory:

cd /var/www/api.example.com
sudo git clone <your-laravel-repo-url> .

2. Configure Apache vhosts

To set up a virtual host for Laravel, follow these steps:

  1. Create a new vhost configuration file for your domain:


sudo nano /etc/apache2/sites-available/api.example.com.conf

  1. Add the following configuration, replacing api.example.com with your domain and ensuring the document root points to your Laravel public directory:


<VirtualHost *:80>
ServerAdmin webmaster@api.example.com
ServerName api.example.com
DocumentRoot /var/www/api.example.com/public<Directory /var/www/api.example.com>
AllowOverride All
Require all granted
</Directory>ErrorLog ${APACHE_LOG_DIR}/error.log
CustomLog ${APACHE_LOG_DIR}/access.log combined
</VirtualHost>

  1. Enable the site and rewrite module:


sudo a2ensite api.example.com.conf
sudo a2enmod rewrite
sudo systemctl restart apache2

This will configure your server to respond to api.example.com and ensure that the .htaccess file in Laravel works as expected.

3. Pointing the Domain to the EC2 Instance with Route 53

To make your domain accessible, you need to configure AWS Route 53 to point your domain to the EC2 instance:

  1. Create a Hosted Zone in Route 53
    In the AWS Management Console, navigate to Route 53 and create a hosted zone for your domain (api.example.com).
  2. Add an A Record
    Once the hosted zone is created, add an A record that points to the public IP address of your EC2 instance:

    • Select Create Record.
    • For Record type, select A – IPv4 address.
    • In the Value field, enter the public IP of your EC2 instance.
    • Set the TTL (Time to Live) as preferred, then click Create records.
  3. Update Your Domain Registrar
    If your domain is registered outside AWS, go to your domain registrar and update the nameservers (NS records) to point to the ones provided by AWS Route 53 for your hosted zone.

This will ensure that when you visit api.example.com, it directs to your EC2 instance.

4. Set up MySQL

Log in to MySQL from the RDS instance

Log in to your MySQL database on Amazon RDS:

sudo mysql -u root -p

Create Database and User

Run the following SQL commands to create a database and a user with proper privileges:

CREATE DATABASE laravel_db;
CREATE USER 'laravel_user'@'%' IDENTIFIED BY 'securepassword';
GRANT ALL PRIVILEGES ON laravel_db.* TO 'laravel_user'@'%';
FLUSH PRIVILEGES;
EXIT;

5. Update the .env File in Laravel

Navigate to the .env file in your Laravel project and update the database configuration to match the details for your RDS instance:

env
DB_CONNECTION=mysql
DB_HOST=<RDS_ENDPOINT>
DB_PORT=3306
DB_DATABASE=laravel_db
DB_USERNAME=laravel_user
DB_PASSWORD=securepassword

6. Installing and Configuring Laravel

Install Laravel Dependencies

Run the following commands to install Laravel’s PHP dependencies:

composer install
php artisan migrate
php artisan key:generate

Configure Sanctum for Token-Based Authentication

In config/auth.php, configure Sanctum to use token-based authentication by updating the 'driver' field:

php

'driver' => 'token',

Next, comment out unnecessary middleware in app/Http/Kernel.php:

php

// \App\Http\Middleware\VerifyCsrfToken::class,
// \Laravel\Sanctum\Http\Middleware\EnsureFrontendRequestsAreStateful::class,

7. Setting Up SSL with Let’s Encrypt

To secure your server with SSL, we will use Let’s Encrypt, a free SSL certificate provider.

Install Certbot

  1. First, add the Certbot repository and install Certbot:
bash


sudo apt install software-properties-common
sudo add-apt-repository ppa:certbot/certbot
sudo apt update
sudo apt install certbot python3-certbot-apache

Obtain an SSL Certificate

  1. To request an SSL certificate for your domain, run the following command:
bash

sudo certbot --apache -d api.example.com
  1. Follow the prompts to complete the process. Certbot will automatically configure Apache for SSL and redirect all HTTP traffic to HTTPS.

Automatic SSL Renewal

  1. To ensure your SSL certificate is renewed automatically, Certbot adds a cron job for renewal. You can test it by running:
bash

sudo certbot renew --dry-run

8. Testing the API

To ensure everything is working, use tools like Postman or Insomnia to test your Laravel API endpoints. Make sure that your Laravel routes, token authentication, and SSL are functioning as expected.

Tags :
API, Laravel, Mobile Application
